Name: Customizable High Precision Spiral Bevel Gear with HRC 58-62 Hardness for Mechanical Power Transmission
Brand: Hunan Ruida Heavy-duty Machinery and Equipment Co., Ltd.
SKU: Custom made
Availability: InStock

Home > Products > Spiral Bevel Gear >

Customizable High Precision Spiral Bevel Gear with HRC 58-62 Hardness for Mechanical Power Transmission

Place of Origin:

Hunan,China

Brand Name:

Ruida

Certification:

ISO9001

Model Number:

Custom made

Request A Quote

Customizable High Precision Spiral Bevel Gear with HRC 58-62 Hardness for Mechanical Power Transmission

Product Details

Payment & Shipping Terms

Minimum Order Quantity

1 sets

Packaging Details

Plywood box

Delivery Time

45-60 days

Payment Terms

T/T

Supply Ability

5000 sets/year

Heavy Duty Spiral Bevel Gear Set with HRC 58–62 Hardness and DIN3965 Class 5–8 Standards for 90° Shaft Angle Power Transmission

Get Best Price

Video

Customizable Material Spiral Bevel Gear Set with Precision Engineering for 90° Angle Torque Transfer

Get Best Price

High Precision Large Diameter Spiral Bevel Gear for Crusher Machine Reducer with Corrosion Resistance

Get Best Price

HB220-280 HRC45-62 Hardness Spiral Bevel Gear Set with Customizable Teeth Number

Get Best Price

+8619073177705

ruidazhongji@sina.com

Contact Now

Product Description

Customizable Spiral Bevel Gear

Available in various modules and sizes suitable for diverse mechanical power transmission needs.

Technical Specifications

Module	1 ~ 45
Teeth Number	6 ~ 120
Shaft Angle	90° (customizable)
Accuracy Grade	DIN 3965 Grade 4 ~ 9
Material	20CrMnTi, 20Cr2Ni4A, 42CrMo, 18CrNiMo7-6
Heat Treatment	Carburizing & quenching, tempering, induction hardening
Surface Hardness	HRC 58 ~ 62
Spiral Angle	15° ~ 45°
Efficiency	≥97%
Max. Speed	≤10000 rpm

Technical Excellence

Design & Geometry

The spiral teeth feature a curved profile that meshes gradually, reducing impact loads and minimizing operational noise. This spiral design also enables higher load-carrying capacity compared to straight-bevel alternatives.

Material & Hardness

Fabricated from premium alloy steel, the gears undergo precision heat treatment (e.g., carburizing, quenching) to achieve a surface hardness of HRC 58–63, ensuring exceptional wear resistance and fatigue strength.

Manufacturing Precision

Employing advanced CNC gear cutting, grinding and scraping technologies, our gear set meets DIN3965 Class 5–8 standards for tooth profile, pitch, and surface finish, guaranteeing seamless meshing and long-term reliability.

Custom Solution Inquiry Process

When you reach out with an inquiry, you have two straightforward paths to kick off your custom solution:

Send Us Your Drawings (Recommended) - Share your detailed specifications, CAD files, or design drawings, and our team will immediately review them to craft a targeted quotation. This streamlined approach cuts down on back-and-forth, ensuring we align on your vision quickly and accurately.
Send Us Your Samples - Prefer to work from a physical reference? Send us your existing product or sample, and we'll analyze its design, materials, and performance to build a matching quote. From there, we'll create precise technical drawings for your approval before moving forward.
